Jalapeno Wireless UHF Reader (coming soon) available to pre-order now for shipment by 15 June 2019
£119.95Add to basketAvailable after 15 June 2019
The RFID UHF Reader is an embedded module which can operate in both host connected and stand alone mode. It’s a compact UHF RFID reader/writer with USB, UART and Wi-Fi (Bluetooth LE coming soon) interfaces, one internal chip antenna for communication with UHF RFID passive tags and U.fl socket for an external antenna (ANT2). With max. 20 dBm power output it can achieve up to 2 meters reading range from the internal antenna and greater range when connected to the external antenna.
The RFID UHF Reader supports all ISO18000-6C (EPC Class1 Gen2) tags, as well as ETSI & FCC frequencies 840-960MHz.
Supply voltage range: 3.6 – 5.5 V
Interfaces: USB, UART TTL, Wi-Fi, WebSockets, MQTT, (Bluetooth LE coming soon). -
Pepper Wireless C1 UART
£31.95Add to basketThe RFID C1 UART is a very powerful, wireless (Wi-Fi now with Bluetooth to follow soon) and low cost full RFID/NFC read/write device with UART interface that can operate in both host connected and stand alone mode. Supports MIFARE® Classic® in 1K, 4K memory, ICODE, MIFARE Ultralight®, MIFARE DESFire® EV1/EV2, MIFARE Plus®.
-
Pepper Wireless C1 USB
£36.95Add to basketThe RFID C1 USB is a very powerful, wireless (Wi-Fi now with Bluetooth to follow soon) and low cost full RFID/NFC read/write device with USB interface that can operate in both host connected and stand alone mode. Supports MIFARE® Classic® in 1K, 4K memory, ICODE, MIFARE Ultralight®, MIFARE DESFire® EV1/EV2, MIFARE Plus®.
-
RFID B1
£13.07Add to basketA surface mount complete RFID reader module supporting MIFARE Classic®, MIFARE Ultralight®, MIFARE EV1®, NTAG2xx® transponders. Serial (UART) interface. Additional features provided are a comparator, DAC, PWM and digital I/O. Connect a 3.3V power supply and an antenna (see our antenna range) to create a working RFID reader. Very fast and very low power. Supports multiple tags simultaneously in the field and stand alone operation as well as connected to a host controller operation. Add as a sub assembly component to your pcb to give RFID capability to your product.
-
RFID A1
£13.07Add to basketA surface mount complete RFID reader module supporting Mifare Classic, Mifare Ultralight, Mifare EV1, NTAG2xx transponders. SPI or I2C interface. Connect a 3.3V power supply and an antenna (see our antenna range) to create a working RFID reader. Very fast and very low power. Supports multiple tags simultaneously in the field and stand alone operation as well as connected to a host controller operation. Add as a sub assembly component to your pcb to give RFID capability to your product.
-
MicroRWD MIFARE
£19.90Add to basketThe MicroRWD MIFARE LP (Low Power) module is a complete read and write solution for 13.56 MHz MIFARE Classic® cards (1K, 4K and Ultralight® versions) and supports MIFARE® contactless operations to dual-interface cards such as MIFARE ProX®, Smart MX® (JCOP) and other types. DESfire® and MIFARE Plus® cards are supported for serial number acquisition only.
-
MicroRWD HITAG2
£13.60Add to basketThe MicroRWD H2 version is a complete reader and tag acceptance solution for Hitag 2 ® RF transponders. The solution only needs a 700uH antenna coil connected and 5 V DC supply to be a fully featured read/write system. Supports access of UID serial number when passwords are unknown. Typical power consumption 50mW (10mA@5V)
-
MicroRWD MICODE
£20.95Add to basketThe MicroRWD MICODE module is a complete “contactless” read / write solution for 13.56 MHz MIFARE Classic® 1K, MIFARE Classic® 4K, MIFARE Ultralight®, ProX®, Smart MX®, JCOP), ICODE® SLI and ISO14443B (Calypso Rev2) cards and tags. DESfire®, MIFARE Plus® and ISO14443B Calypso cards are supported for serial number acquisition only.
-
MicroRWD QT
£13.60Add to basketThe MicroRWD QT (Quad-Tag) version is a complete 125kHz reader solution for Hitag 1, Hitag S256/S2048 (Plain Memory mode), Hitag 2 (Password mode), EM400X/4102 and MCRF200I/123 passive RFID transponder types.
-
Chilli UART-B1
£16.54Add to basketA low cost full RFID/NFC read/write device that can operate in “host” connected mode or “stand alone” mode. Supports MIFARE Classic® 1K, MIFARE Classic® 4K, NTAG2xx®, MIFARE Ultralight®. Based on our RFID-B1 with additional integral antenna, LED for card in the field indication/ interrupt, mounting holes and flexible plated connection holes.
-
Chilli USB-B1
£18.11Add to basketA low cost full RFID/NFC read/write device that can operate in “host” connected mode or “stand alone” mode. Supports MIFARE Classic® 1K and MIFARE Classic® 4K, NTAG2xx®, Ultralight. Based on our RFID-B1 with additional integral antenna, USB interface (FTDI virtual COM port, micro USB connector), powered by USB, LED for card in the field indication/ interrupt, mounting holes and flexible plated connection holes. Free software libraries for C, C#, Java, Linux, Arduino.
-
Chilli RS232-B1
£17.59Add to basketA low cost full RFID/NFC read/write device that can operate in “host” connected mode or “stand alone” mode. Supports MIFARE Classic® 1K, MIFARE Classic® 4K, NTAG2xx®, MIFARE Ultralight®. Based on our RFID-B1 with additional integral antenna, RS232 interface, up to continuous 25V DC power connection, LED for card in the field indication/ interrupt, mounting holes and flexible plated connection holes. Free software libraries for C, C#, Java, Linux, Arduino, Altium/CS footprints, PCB antenna designs.
-
UART-B1
£13.60Add to basket*LIMITED STOCK ITEM* – this version has no LED to indicate a tag presence in the field.
A low cost full RFID/NFC read/write device that can operate in “host” connected mode or “stand alone” mode. Supports MIFARE Classic® 1K, MIFARE Classic® 4K, NTAG2xx®, MIFARE Ultralight®. Based on our RFID-B1 with additional integral antenna, mounting holes and flexible plated connection holes. The difference
-
RaspberryPi-B1
£23.05Read moreThe RaspberryPi-B1 module is an expansion of the RFID B1 module – the second in an evolving family of 13.56 MHz sub assemblies from Eccel Technology Ltd (IB Technology). The product is designed with both embedded applications and computing / PLC platforms in mind. This product is an ideal design choice if the user wishes to add RFID capability to their design quickly and without requiring extensive RFID and embedded software expertise and time. An on board low power ARM microcontroller handles the RFID configuration setup and provides the user with a powerful yet simple command interface to facilitate fast and easy read/write access to the memory and features of the various transponders supported by this module. This device is designed to be compatible with the Raspberry Pi Hat standard.
-
USB-B1
£24.10Add to basketComplete Evaluation and Software Development Board for the RFID-B1 module (supporting ISO 14443A, MIFARE Classic® 1K, MIFARE Classic® 4K, MIFARE Ultralight®, NTAG2xx® card/tag types). This board is also suitable for use as a standalone OEM reader/writer product of these transponder types.
-
MicroRWD QT LP SMT
£12.55Add to basketSurface mount version of 125 kHz RFID reader module supporting several transponder/tag types. NXP Hitag 1, Hitag S, Hitag 2, EM4001 / EM4102 and Microchip MCRF200/123 tag types.
